Produktdetails


Performance data DKF+060S-MF1-3-5C1-1K00
Max. torque T
36 Nm
Emergency stop torque
40 Nm
Max. input speed
7,500 min-1
Permitted average input speed
2,200 min-1
Max. tilting moment
251 Nm
Max. axial force
2,400 N
Max. lateral force
2,700 N
Mass moment of inertia
0.57 kgcm2
Weight
2.9 kg
Lubrication
Lubricated for life
Max. permitted housing temperature
90 °C
Protection class
IP 65
Operating noise
≤ 64 dB(A)




Performance data DKF+090S-MF1-3-5C1-1K00
Max. torque T
84 Nm
Emergency stop torque
95 Nm
Max. input speed
7,500 min-1
Permitted average input speed
2,100 min-1
Max. tilting moment
437 Nm
Max. axial force
3,400 N
Max. lateral force
4,000 N
Mass moment of inertia
1.81 kgcm2
Weight
5.3 kg
Lubrication
Lubricated for life
Max. permitted housing temperature
90 °C
Protection class
IP 65
Operating noise
≤ 66 dB(A)



Performance data DKF+0120S-MF1-3-5C1-1K00

Max. torque T
204 Nm
Emergency stop torque
220 Nm
Max. input speed
5,500 min-1
Permitted average input speed
2,000 min-1
Max. tilting moment
833 Nm
Max. axial force
5,700 N
Max. lateral force
6,300 N
Mass moment of inertia
5.46 kgcm2
Weight
8.9 kg
Lubrication
Lubricated for life
Max. permitted housing temperature
90 °C
Protection class
IP 65
Operating noise
≤ 66 dB(A)




Performance data DKF+0140S-MF1-3-5C1-1K00

Max. torque T
360 Nm
Emergency stop torque
400 Nm
Max. input speed
5,000 min-1
Permitted average input speed
1,700 min-1
Max. tilting moment
1,692 Nm
Max. axial force
9,900 N
Max. lateral force
9,500 N
Mass moment of inertia
28.4 kgcm2
Weight
22 kg
Lubrication
Lubricated for life
Max. permitted housing temperature
90 °C
Protection class
IP 65
Operating noise
≤ 68 dB(A)


Performance data DKF+0180S-MF1-3-5C1-1K00
Max. torque T
768 Nm
Emergency stop torque
900 Nm
Max. input speed
4,500 min-1
Permitted average input speed
1,400 min-1
Max. tilting moment
3,213 Nm
Max. axial force
14,200 N
Max. lateral force
14,700 N
Mass moment of inertia
96.49 kgcm2
Weight
48 kg
Lubrication
Lubricated for life
Max. permitted housing temperature
90 °C
Protection class
IP 65
Operating noise
≤ 68 dB(A)


Every A&G gearbox requires a mounting flange and shaft bushing to match the gear to the motor. Please select the proper flange and bushing for your specific motor from the table below.

Contact us in case you could not find the flange matching your motor and we will be happy to quickly design it for you.

Each size of gearboxes has up to 3 different coupling diameters, so the bushing is thin enough to transmit the motor torque without sliding. You will find the eventual bushing needed in the column on the right.

Just select the flange and bushing references below, corresponding to your motor dimensions.

Do not hesitate to contact us for a drawing corresponding to your motor reference, or if you are not sure about the exact flange and bushing.
