DP-M planetary gearbox
DP+ planetary gearbox
The high-precision powerhouse
This gearbox series sets standards in terms of power density, modularity and easy installation. It is used in all applications where the individual requirements far exceed what has previously been possible. RP+ gearboxes combine all the advantages of the familiar gearbox series:
Reduced backlash of ≤ 1 arcmin
Maximum power density
Extremely smooth-running thanks to helical toothing
Performance data DP-135-GF1-5.5-5C1-1K00
Ratio：：5.5 16 22 27.5 38.5 55 66 88 110 154 220
Max. torque T2α185 Nm
Emergency stop torque313 Nm
Max. input speed5,500 min-1
Permitted average input speed2,000 min-1
Max. tilting moment1,800 Nm
Max. axial force4,600 N
Mass moment of inertia6.1 kgcm2
Weight14 kg
LubricationLubricated for life
Max. permitted housing temperature90 °C
Protection classIP 65
Operating noise≤ 65 dB
Performance data DP-167-GF1-5.5-5C1-1K00
Ratio：：5.5 16 22 27.5 38.5 55 66 88 110 154 220
Max. torque T2α 435 Nm
Emergency stop torque313 Nm
Max. input speed5,500 min-1
Permitted average input speed2,000 min-1
Max. tilting moment1,800 Nm
Max. axial force4,600 N
Mass moment of inertia6.1 kgcm2
Weight14 kg
LubricationLubricated for life
Max. permitted housing temperature90 °C
Protection classIP 65
Operating noise≤ 65 dB
Performance data
Performance data DP-200-GF1-5.5-5C1-1K00
Ratio：5.5 16 22 27.5 38.5 55 66 88 110 154 220
Max. torque T2α1,402 Nm
Emergency stop torque2,865 Nm
Max. input speed5,000 min-1
Permitted average input speed2,500 min-1
Max. tilting moment3,600 Nm
Max. axial force10,000 N
Mass moment of inertia26.4 kgcm2
Weight23 kg
LubricationLubricated for life
Max. permitted housing temperature90 °C
Protection classIP 65
Operating noise≤ 63 dB(A)
Performance data
Performance data DP-276-GF1-5.5-5C1-1K00
Ratio：5.5 16 22 27.5 38.5 55 66 88 110 154 220
Max. torque T2α 3,822 Nm
Emergency stop torque6,250 Nm
Max. input speed4,500 min-1
Permitted average input speed1,500 min-1
Max. tilting moment11,000 Nm
Max. axial force26,000 N
Mass moment of inertia58.5 kgcm2
Weight57 kg
LubricationLubricated for life
Max. permitted housing temperature90 °C
Protection classIP 65
Operating noise≤ 66 dB(A)
Performance data DP-327-GF1-5.5-5C1-1K00
Ratio：5.5 22 27.5 38.5 55 66 88 110 1542 20
Max. torque T2α 7,360 Nm
Emergency stop torque 10,938 Nm
Max. input speed 3,125 min-1
Permitted average input speed 1,000 min-1
Max. tilting moment 21,000 Nm
Max. axial force 58,500 N
Mass moment of inertia162 kgcm2
Weight93 kg
LubricationLubricated for life
Max. permitted housing temperature90 °C
Protection classIP 65
Operating noise≤ 68 dB(A
Performance data DP-368-GF1-5.5-5C1-1K00
Ratio：5.5 22 27.5 38.5 55 66 88 110 154 220
Max. torque T2α 10,450 Nm
Emergency stop torque18,750 Nm
Max. input speed3,125 min-1
Permitted average input speed900 min-1
Max. tilting moment34,000 Nm
Max. axial force67,500 N
Mass moment of inertia224 kgcm2
Weight133 kg
LubricationLubricated for life
Max. permitted housing temperature90 °C
Protection classIP 65
Operating noise≤ 68 dB(A)
